SQLite Across Every Port: One Contract, One Encrypted File Format

The original com.codename1.db implementation delegated SQLite calls to the database supplied by each operating system. We knew this was less portable than the rest of Codename One, but fixing it meant taking ownership of SQLite on every target. That looked like a deep rabbit hole, so we exposed escape hatches instead. The pluggable SpatiaLite work we described in 2018 is one example.

On Windows and Linux, Database.openOrCreate() returned null. JavaScript depended on WebSQL, which Chrome removed and Firefox never implemented. An iOS cursor could report success on an empty result set, then read unset memory. The simulator counted rows from one while the other ports counted from zero. Encryption had no sensible place to live because there was no single database contract underneath it.

PR #5526 follows that rabbit hole to the end. It replaces the platform-dependent implementations with one specified and tested SQLite contract. It also resolves the long-standing encrypted database request. The same encrypted file can move between ports and open in a standard SQLCipher 4 client.

TL;DR

• SQLite now has one tested contract, including native Windows and Linux implementations, SQLite compiled to WebAssembly for JavaScript, and encryption with three key models.
• The watch apps deep dive treats the phone and watch as separate applications with separate lifecycles. WearableConnection gives them one asynchronous API for messages, replicated state, and files.
• JavaScript text now appears as real DOM text above the canvas. Browser search, selection, accessibility, autofill, and native-resolution rendering work without handing layout to the browser.
• Smart home support maps HomeKit, Matter, and Google Home concepts onto com.codename1.home, including a simulated house for desktop development.
• Tapjacking protection detects and can reject Android gestures that begin behind another app’s overlay.
• Camera and vision regain the one-call ergonomics that were lost when the old scanner libraries were replaced by lower-level on-device analyzers.
• App Intents expose a Java handler to Siri, Spotlight, Shortcuts, Android launcher shortcuts, and an internal command layer.

Each port had different SQLite behavior

The old API looked uniform because every port implemented the same Java methods. That said nothing about the result.

execute(sql) ran every statement on iOS, but silently stopped after the first statement in the simulator. getBlob() returned nil on iOS. The JavaScript cursor’s position(n) always landed on row zero. The simulator leaked a prepared statement per query. ThreadSafeDatabase.close() returned before the close happened, so an immediate delete could race it.

These were not edge cases around a working abstraction. They meant a query tested in the simulator could have different transaction, cursor, or binding behavior on a device.

The new DatabaseConformanceSuite defines the contract once. Seven device tests exercise lifecycle, statements, cursors, transactions, encryption, and legacy behavior on every port-status target. The current reports show those tests passing on Android, both iOS renderers, JavaScript, native Linux, native Windows, macOS, tvOS, and watchOS.

Cursor navigation now derives from two primitives, rewind() and stepForward(), instead of being reimplemented on every port. Transactions return to autocommit after either commit or rollback. Blobs and typed parameters behave consistently. Windows and Linux finally open a database instead of returning null.

Fixing these inconsistencies changes behavior that some existing applications may rely on. A cursor index or transaction quirk can become part of application code even when the behavior was accidental. The db.legacy build hint keeps the previous implementations available during migration.

Older Ant projects default to legacy mode. They may be stable applications that only need another maintenance release, and forcing a database migration on them would be reckless. Newer Maven projects default to the corrected contract so new code does not inherit the old problems. Either project type can set db.legacy=true for the old behavior or db.legacy=false for the corrected contract.

DatabaseConfig opens the same encrypted format everywhere

Encryption is selected by passing a DatabaseConfig when the database opens:

if (Database.isEncryptionSupported()) {
    DatabaseConfig config = DatabaseConfig.managed();
    Database db = null;
    try {
        db = Database.openOrCreate("secure.db", config);
        // Read and write through db.
    } finally {
        config.wipe();
        if (db != null) {
            db.close();
        }
    }
}

There are three key models:

A passphrase compiled into the application is recoverable from the shipped binary. It is not a useful secret. A managed key avoids that mistake, but it also changes the recovery story: if the key-store entry is lost, the database is unreadable. Use a user-held or server-held passphrase when the data must survive a device loss.

Existing plaintext databases can be converted without replacing the API:

if (!Database.isEncrypted("customer.db")) {
    Database.encrypt("customer.db", DatabaseConfig.managed());
}

The on-disk parameters are fixed to the SQLCipher 4 format: AES-256-CBC, PBKDF2-HMAC-SHA512 with 256,000 iterations, 4,096-byte pages, and per-page HMAC-SHA512. CI writes a database with the Codename One engine and reads it with the stock sqlcipher client, then reverses the direction. That cross-engine test catches a class of failure where every port can read its own incompatible file.

Encryption protects data at rest. It does not protect an open database from a debugger, a memory dump, or code already running on a compromised device. That boundary is why this work sits beside App Shield and App Hardening instead of replacing either one.

JavaScript gets SQLite instead of a removed browser API

The JavaScript port used WebSQL because browsers once exposed it as a convenient SQL-shaped store. Chrome removed WebSQL in version 119. Firefox never shipped it. A portable API cannot depend on a feature that no longer exists in one browser and never existed in another.

JavaScript now runs SQLite compiled to WebAssembly and stores the database in the browser’s storage pool. It passes the same statement, cursor, transaction, encryption, and compatibility tests as the native ports.

The new engine cannot read an old WebSQL store. openOrCreate() refuses to create an empty database when it detects that old data, because silently replacing a user’s database with an empty state is worse than a visible migration. An application with WebSQL-era users must export from a build that can still read the old store, or deliberately opt into a new empty database with cn1.db.ignoreLegacyWebSql=true.

The build also remains pay-for-what-you-use. An application that never references com.codename1.db gets no database engine. A plain JavaScript database adds roughly 1.5 MB of WebAssembly. Referencing DatabaseConfig adds the cipher implementation where the platform needs it.

On Android, encryption raises the minimum SDK to 23 and requires AndroidX because those are SQLCipher’s requirements. The unencrypted database path keeps the older floor.

That covers the database work. Six more changes shipped this week, each with its own detailed post.

The watch and phone now run as separate applications

A watch is not a small second window owned by the phone process. It has its own executable, storage, startup sequence, and failure modes. The watch applications post covers the complete model introduced by PR #5487.

One codename1.watchMain setting adds the Apple Watch companion entry point. On Android, codename1.watchStandalone=true builds that entry point as the Wear OS product instead of the phone application; a companion Wear artifact beside the phone APK is not generated yet. The simulator can launch the phone and watch as separate processes and connect them on the desktop. The pair shares source, resources, CSS, and the surfaces model. It does not share Storage, Preferences, or SQLite.

WearableConnection models the three transports the platforms actually provide. sendMessage() asks a live peer for an immediate reply. putData() replicates the latest state and survives sleep or relaunch. transferFile() moves a larger payload in the background. The API uses WCSession on Apple platforms and the Wearable Data Layer on Android.

WearableConnection.putData(new WearableMessage("/steps")
        .put("count", stepCount)
        .put("goalReached", stepCount >= 10000));

Complications join the existing surfaces vocabulary through watch-specific WidgetSize families. This reuses the same content and timeline model already used for widgets and Live Activities. The generated watchOS complication target and Wear OS complication service are not part of this release yet. Android also supports standalone Wear apps today, but does not yet generate a companion Wear artifact beside a phone APK.

Browser search now works in the JavaScript port

The JavaScript port has always rendered through a canvas. That gives Codename One control over layout and keeps the UI consistent, but it also turned visible text into pixels. Browser search could not find it. Users could not select it. The browser could not rasterize it at native resolution or expose it as ordinary text.

The JavaScript text post explains how PR #5552 keeps the canvas renderer and adds two targeted DOM layers above it. The text layer holds visible text runs at the positions Codename One already calculated. The accessibility layer holds the ARIA projection and updates it incrementally.

<canvas role="presentation" aria-hidden="true"></canvas>
<div id="cn1-text-layer" aria-hidden="true">Selectable, searchable text</div>
<div id="cn1-accessibility-tree" aria-label="..."></div>

The browser never gets to reflow a line or decide where a component belongs. It gets text that is already measured, broken, and positioned. Find-in-page, text selection, accessibility, native input metadata, password-manager hints, and high-DPI rendering can then use browser machinery without changing application layout.

Drag selection is still off because the text layer cannot take pointer events without changing canvas hit testing. Shape-clipped and transformed text stays on the canvas. Same-form occlusion, such as a sheet over text in the underlying form, also needs more work.

One API for HomeKit, Matter, and Google Home

The smart-home post introduces com.codename1.home from PR #5554, a common model for HomeKit, Matter, and Google Home. An accessory contains services. Services expose canonical traits such as ON_OFF, BRIGHTNESS, and TARGET_TEMPERATURE. Platform identifiers and unit conventions stay in the port.

That sounds like a normal abstraction until the platforms disagree. Matter and HomeKit express covering position in opposite directions. Matter has no single thermostat setpoint in automatic mode. Android can commission a Matter accessory into Google Home with little setup, but reading the accessory graph requires Google Home developer registration that Codename One cannot create for you.

The API reports that default Android state as COMMISSIONING_ONLY, not AVAILABLE. On iOS it can read and write HomeKit traits, run scenes, and commission Matter accessories. The simulator, desktop ports, and JavaScript run a deliberately awkward synthetic house so missing values, partial failures, and polling behavior can be tested without hardware.

Automations, background accessory events, camera streams, alarm panels, and the Google Home accessory graph on Android are outside this release. Each gap has a capability query or a specific availability state instead of turning into an empty list that looks like a real answer.

Tapjacking protection continues our security hardening work

We are continuing the push to make Codename One the secure default for application developers. The tapjacking protection post covers the input side of that work. Tapjacking happens when another Android application draws over a sensitive screen and changes what the user believes a tap will do. PR #5553 adds a TapjackingPolicy to DeviceIntegrity.

DeviceIntegrity.setTapjackingProtection(TapjackingPolicy.BLOCK);
DeviceIntegrity.addTapjackingListener(event -> {
    if (Boolean.TRUE.equals(event.getSource())) {
        showOverlayWarning();
    }
});

if (DeviceIntegrity.isHideOverlayWindowsSupported()) {
    DeviceIntegrity.setHideOverlayWindows(true);
}

REPORT observes without changing input. BLOCK drops a gesture that begins fully obscured. STRICT also drops partially obscured gestures, which can include ordinary system UI and therefore carries a real false-positive cost.

Detection is touch-driven because Android supplies the obscured state on MotionEvent. An overlay that appears without a touch is not detected by polling. On Android 12 and newer, setHideOverlayWindows(true) prevents overlay windows instead of reacting to their touches. iOS does not let one application draw over another, so the policy is an Android-only control rather than a fake cross-platform checkbox.

Scan a barcode without rebuilding the camera pipeline

The on-device vision work added barcode recognition, face and pose detection, text recognition, segmentation, document scanning, and image labeling. It also exposed every piece of the camera-to-analyzer pipeline. That was useful for custom camera products and needlessly low-level for common cases.

The camera and vision post covers the higher-level APIs in PR #5575. CodeScanner.scan() owns a complete scanner screen and returns one asynchronous result:

CodeScanner.scan().ready(code -> {
    if (code != null) {
        urlField.setText(code.getValue());
    }
}).except(error -> Log.e(error));

VisionCameraView packages the same pipeline as a component for a form you own. Typed BarcodeFormat, FaceLandmarks, and PoseLandmarks constants replace string literals. VisionRect.toBounds(...) and VisionPoint.toPoint(...) convert normalized analyzer geometry into component coordinates. SegmentationMask.cutOut(...) turns selfie segmentation into a usable image operation.

The preview remains a native peer. Components cannot be painted over it uniformly on every target, so controls and reticles should sit around it. One camera session can be open at a time. The simulator now scripts vision results, which lets the flow, overlay geometry, cancellation, and error paths run before the application reaches a device.

Expose an intent to Siri, Spotlight, and Shortcuts

The App Intents post shows how to expose a Java method to Siri, Spotlight, Shortcuts, or an Android launcher shortcut. PR #5559 puts the declaration in Java:

@AppIntent(value = "log_workout", title = "Log a workout",
        phrases = {"Log a workout in ${applicationName}"}, headless = true)
public static IntentResult logWorkout(
        @IntentParam("minutes") int minutes) {
    WorkoutStore.append(minutes);
    return IntentResult.spoken("Logged " + minutes + " minutes.");
}

The Maven plugin reads the compiled bytecode and generates a reflection-free dispatch table plus the native declarations. The direct static call matters on iOS, where runtime annotation lookup is unavailable and dead-code elimination can remove a handler that has no Java caller.

Entities let the platform ask the user which application object they meant. Intents.index(...) publishes those objects to device search. opensRoute connects an intent to the existing route table when the result should foreground a screen.

Android is not presented as Siri parity. It gets launcher shortcuts, donation, indexing, and headless execution. Voice invocation, system disambiguation, and spoken assistant results are iOS capabilities. Intents.invoke(...) still works on every port as an internal command layer, even when the operating system exposes no intent surface.

Security now covers storage, code, backend trust, and input

This week closes several gaps that used to be explained away as platform differences. SQLite now has one documented contract and one portable encrypted format. The watch and phone are separate applications with a defined channel. Smart-home traits and app intents project one application model onto native system services without pretending those services are identical. The web port keeps our renderer while restoring browser behavior users expect.

App Shield moves trust decisions to the backend. App Hardening raises the cost of reading and modifying the shipped binary. Encrypted SQLite protects stored data. Tapjacking protection rejects a class of misleading input on Android. None of these controls makes a compromised device trustworthy. Together they cover more of the path from stored bytes to the tap that authorizes an operation.

We want Codename One to lead cross-platform development on security. That requires more than adding isolated security switches. The safe path must be available from ordinary application code, included only when used, and tested on every target we claim to support. This week’s encrypted database and tapjacking work move two more boundaries into that default path.

Start with the database guide if you have data at rest to migrate. Existing Ant applications should set db.legacy explicitly before moving to Maven. Applications with WebSQL-era browser data need an export plan before taking the new JavaScript engine.
